Centrifugal Pumps
Centrifugal pumps are used to transport fluids by the conversion of rotational kinetic energy to the hydrodynamic energy of the fluid flow. The rotational energy typically comes from an engine or electric motor. The fluid enters the pump impeller along or near the rotating axis and is accelerated by the impeller flowing radially outward into a diff-user or volute casing, from where it exits.
| Technical Data | RPM: N=2850 R/MIN(50hz); N=3450 R/MIN (60HZ) |
|---|
| Model | Power | Inlet | Outlet | Max. Flow | Max. Head | Max. Suction |
PRICE Excl. VAT |
|
| Single-Phase | kW | HP | (Inch) | (Inch) | (m3/h) | (m) | (m) | |
| JET100P | 0.75 | 1 | 1 | 1 | 3.5 | 46 | 9 | Contact For Price |
| Cpm158 | 0.75 | 1 | 1 | 1 | 6.5 | 32 | 7 | Contact For Price |
| Cpm170 | 1.1 | 1.5 | 1.25 | 1 | 7.2 | 44 | 7 | Contact For Price |
| SHFm5A | 1.1 | 1.5 | 2 | 12 | 21 | 14 | 7 | Contact For Price |
| SHFm6AR | 2.2 | 3 | 4 | 4 | 72 | 18.5 | 7 | Contact For Price |
| 2SGPm25/140 | 1.1 | 1.5 | 25 | 25 | 10.2 | 42 | 8 | Contact For Price |
| 2SGPm25/160B | 1.5 | 2 | 25 | 25 | 12 | 50 | 8 | Contact For Price |
